Connecting Block R30-90° Kit – Series 6 Aluminium Profile Connectors
£4.25 exc VAT
Download Dimensions as PDF
Download Step File
Download Step File 2
Note: If you experience download issues, right click the link and select "Save link as".
- Durable robust design
- Easy customisation
- High quality materials
- Versatile profiles & components
When building robust structures with aluminium profiles, the right connectors make all the difference. The Connecting Block R30-90° Kit – Series 6 is an essential end plate connecting solution designed for Series 6 aluminium profiles. Whether you’re constructing workstations, furniture, table frames, or enclosures, this kit offers precision, strength, and flexibility for a wide range of applications.
Series 6 aluminium profiles, with their 30mm core dimension and 6mm slot, provide a perfect balance between strength and versatility. With a maximum slot nut thread size of M6, the Connecting Block R30-90° Kit – Series 6 ensures secure, reliable joints for heavier applications compared to Series 5 profiles. This kit is ideal for builders, engineers, and DIY enthusiasts who require durable connections without compromising on style or functionality.
Why Choose the Connecting Block R30-90° Kit – Series 6?
The Connecting Block R30-90° Kit – Series 6 has been carefully designed to complement the Series 6 aluminium profile system. Its robust construction guarantees long-lasting performance even under rigorous usage conditions. Here are some key reasons why this kit stands out:
- Precise 90° Connection: The kit allows for perfectly squared connections between Series 6 profiles, ensuring stability and precision in your assemblies.
- Versatility in Applications: Perfect for modular furniture, shelving systems, table top frames, enclosures, and other larger aluminium profile constructions.
- Compatibility: Specifically engineered for Series 6 profiles, accommodating the 6mm slot and M6 threaded fasteners.
- Strength and Durability: Stronger than Series 5 connectors, this kit can handle heavier loads while maintaining structural integrity.
- Complete Kit: Comes with all necessary components for easy installation, including the connecting block, screws, and mounting accessories.
Part of the Series 6 range of aluminium profile & components
Being part of the Series 6 6mm t-slot profile range, this product is compatible with a wide range of profiles, cable management, castors, feet and base plates, connector elements, cover & reduction profiles, door elements, end caps, glazing accessories, handles, hinges, levelling pads, slot nuts, and tools. The versatile range of profiles and components allow you to build a variety of custom and bespoke projects for private or commercial use.
Series 6 Aluminium Profiles: A Robust Foundation
Series 6 profiles are ideal for larger-scale aluminium constructions. With their 30mm core dimension and 6mm slots, they allow for M6 thread fasteners, providing greater load-bearing capabilities than smaller profile series. The Connecting Block R30-90° Kit – Series 6 complements these profiles perfectly, offering the strength needed for demanding applications.
The versatility of Series 6 profiles extends beyond structural applications. With new flat finish profiles now available, the system is suitable for aesthetic furniture designs, industrial enclosures, and complex frames. Coupled with the extensive range of ancillary parts such as hinges, handles, slot nuts, and connectors, the Series 6 system ensures that your constructions are both functional and visually appealing.
Easy Installation with Maximum Reliability
One of the biggest advantages of the Connecting Block R30-90° Kit – Series 6 is its ease of use. The kit is designed for straightforward assembly, allowing even those new to aluminium profile systems to achieve professional results. The end plate connecting block provides a secure anchoring point, ensuring that your frames and structures remain stable and aligned over time.
Installation is simple: align the Series 6 profiles at a 90° angle, insert the connecting block, and tighten with the included M6 screws. The kit’s precise manufacturing tolerances guarantee a snug fit, reducing the risk of misalignment or wobbling. This makes it an excellent choice for both commercial and DIY projects, where reliability is critical.
Applications of the Connecting Block R30-90° Kit – Series 6
The Connecting Block R30-90° Kit – Series 6 is highly versatile, supporting a wide range of applications across industries. Some popular uses include:
- Modular Furniture: Build tables, cabinets, and storage units with strong, precise joints.
- Workstations: Assemble ergonomic and durable workbenches for industrial or office use.
- Enclosures and Frames: Create protective or decorative enclosures for machinery, electronics, or display units.
- Custom Fixtures: Perfect for bespoke applications where standard connectors cannot meet the design requirements.
Thanks to its robust aluminium construction and precise 90° alignment, this kit provides professional results that last. Whether for heavy-duty industrial projects or refined furniture designs, the Connecting Block R30-90° Kit – Series 6 ensures your frames are strong, aligned, and dependable.
Advantages Over Other Series
While Series 5 profiles are suitable for lighter-duty applications, the Series 6 profile combined with the Connecting Block R30-90° Kit – Series 6 provides greater strength and flexibility. Series 8 profiles are stronger still, making them ideal for extremely heavy-duty uses, but for most furniture, workstation, and enclosure projects, Series 6 offers the perfect balance of performance and affordability.
By using the Connecting Block R30-90° Kit – Series 6, you can:
- Achieve higher load capacity compared to Series 5.
- Maintain modularity with easy assembly and disassembly.
- Utilize a wide variety of ancillary parts for custom solutions.
- Ensure compatibility with standard M6 slot nuts for reliable fastenings.
High-Quality Materials for Long-Term Performance
Constructed from premium aluminium alloy, the Connecting Block R30-90° Kit – Series 6 is corrosion-resistant, lightweight, and highly durable. This ensures your frames and assemblies remain stable and visually appealing even in challenging environments.
The aluminium material also provides excellent rigidity without adding unnecessary weight. This makes it perfect for modular constructions where both strength and portability are important. With precision-engineered components, the kit offers a perfect fit with every Series 6 profile, enhancing structural stability and reducing the risk of failure.
Comprehensive Support and Compatibility
Valuframe’s Connecting Block R30-90° Kit – Series 6 is designed with compatibility in mind. It works seamlessly with the full range of Series 6 profiles, including the latest flat finish profiles. In addition, it is compatible with all standard ancillary components, such as:
- Hinges
- Handles
- Slot nuts
- Connectors
This ensures that your aluminium profile projects can grow and adapt over time. Whether you’re expanding a workstation, modifying a table frame, or adding shelving, the Connecting Block R30-90° Kit – Series 6 provides a reliable foundation for all your modular needs.
For anyone building with Series 6 aluminium profiles, the Connecting Block R30-90° Kit – Series 6 is an essential accessory. Combining strength, versatility, and ease of installation, this kit ensures that your frames, furniture, and enclosures are stable, reliable, and professionally finished. With precise 90° alignment, compatibility with M6 fasteners, and premium aluminium construction, it’s the ideal choice for both professional and DIY applications.
Upgrade your aluminium profile assemblies today with the Connecting Block R30-90° Kit – Series 6—the secure, versatile, and reliable solution for all your modular building needs.
Please make sure this is the correct series part to match the profile series you are purchasing or using. Thank you.
